Akustik dB Finder
NRC Canada
Configuration C1 + F1
Date: 4/27/2022
| Ln,w(CI) | IIC | Rw(C,Ctr) | STC |
|---|---|---|---|
| 41(-) | 69 | 76(-,-) | 76 |
| No. | Component | Material | Height | Width | Weight |
|---|---|---|---|---|---|
| 1 | 2x Plywood | Madera | 0.75 in | -- | -- |
| 2 | Wooden battens | Madera | 3.5 in | -- | -- |
| 3 | Akustik + Sylomer Floor Mount 25 | Sylomer | 4.57 in | -- | -- |
| 4 | Glass Fibre Insulation | Aislante | 3.5 in | -- | -- |
| 5 | Concrete slab | Hormigón | 6.1 in | -- | -- |
| 6 | C-Channel | Acero | 0.91 in | -- | -- |
| 7 | Akustik+ Sylomer Sound Clip 30 | Sylomer | 0.67 in | -- | -- |
| 8 | Glass Fibre Insulation | Aislante | 0.98 in | -- | -- |
| 9 | 2x Plasterboard plates | Pladur | 0.63 in | -- | -- |
